'70 Plymouth Rear Suspension Pictures

[MoparHonda]

I'm taking the rear springs out of my '70 Plymouth GTX for re-arching, so I'm going to put it all back together as correctly to original as I can.

Does anyone have any pictures of an original '70 Plymouth rear suspension? What color should the springs, shackles, bolts, etc be? What color should the front mounting bracket be?



[PurpleBeeper]

Somebody here knows. The springs are not painted



[Billccm]

Check the book by Kevin Shaw & Mike Wilkins
I believe he lists these details and pictures.
I have the book and can look later for you.



[MoparHonda]

Thank you, BillCCM, saw that book, can't find a photo of the shackles, what color are they painted?



[Billccm]

Here's the rear finishes from the book



[MoparHonda]

Thank you, Bill, just what I need.



[69bfan]

If your original pieces have never been touched, they are your best source of information. Check for traces of paint between the leafs of the spring assembly. I am not as knowledgeable of the 70 B-Body as I am for the 68 to 69 B-Body applications. But you will find them in either the heat treated natural finish or a black finish. The front mounting shackle will usually be a natural material with the attaching studs and nuts in a black phosphate finish. The leaf spring plates were natural that were dipped in cosemeline to protect them. The U-Bolts and nuts were a black phosphate finish. Rear shackles were natural finish and the nut was a black phosphate finish. The vacuum plates is a grayish-black phosphate finish with the attaching hardware being a black phosphate. Wheel cylinders were the natural cast iron finish.

Seeing that your rebuilding your originals, there is a kit available now that includes the plastic and zinc interliners, metal and rubber straps, center I-Bolts, U-Bolts and the front and rear shackle bushings to make the job easier if your looking for a correct style hardware kit.



[MoparHonda]

Thank you. 69BFan.

My car was redone back in the 80's and I seem to have a mixture of original and aftermarket parts, I'm having trouble telling which is which; I did some research and I now think I know which is original, now I just need to get original replacements for the non-original stuff.
