Looking for a drawing for the crank to flex plate/flywheel bolt pattern

[Dave Hawkins]

Hi all,
I have a '65 Dodge Coronet, my first car, purchased around 1900 and 75! I've located a drawing on a machinist website for the bell housing dimensions, but I'm also looking for the crank shaft to flex plate/flywheel bolt pattern dimensions and center hole dimensions. I would appreciate any help in locating a drawing, and this would be for the Chrysler RB engines 383, 413, 426, and 440.
Thanks for your time,
Dave



[Pops1967GTX]

Take a look at this, might be helpful...













http://www.mymopar.com/downloads/440_crank_torque_conv_identity_chart.jpg



[Dave Hawkins]

Pops1967GTX,
Thanks for the reply. That image brought me to this forum! I forgot to say that I'm looking for the six bolt pattern dimensions.
Dave

Take a look at this, might be helpful...













http://www.mymopar.com/downloads/440_crank_torque_conv_identity_chart.jpg



[Ron 73]

Welcome aboard Dave! Lots of great folks to help here...



[Budnicks]

welcome to FBBO, maybe you could post your question in the appropriate forum you will get maybe more answers too... good luck



[WP29440SE]

Thanks for the reply. That image brought me to this forum! I forgot to say that I'm looking for the six bolt pattern dimensions.
Dave

welcome, are you trying to make a flexplate, locate one ? what exactly are you doing? i have one out in the garage if i can help with something



[super-bee_ski]

Welcome aboard!
Thanks for joining.



[Dave Hawkins]

[h=2]Budnicks and All,[/h]Appropriate forum? Like the Engine, Trans & Driveline forum on this website?
Thanks,
Dave

welcome to FBBO, maybe you could post your question in the appropriate forum you will get maybe more answers too... good luck

- - - Updated - - -

Super77se and All,
Thanks, I do have a flex plate, but was trying to avoid measurement errors. I am adapting an electric motor, or motors, to a transmission! You can check out the project on our website:
http://www.bbevs.com/
Thanks,
Dave

welcome, are you trying to make a flexplate, locate one ? what exactly are you doing? i have one out in the garage if i can help with something
