i noticed the right side of my 383 in my 68 charger appears to be slightly lower than the left side (appears to be 1/16-1/8 or so). i am looking at the k member and center link relative to the oil pan and they are not perfectly parallel. i noticed it when i hooked up the center link. i have new rubber isolators from 440 source, the ones built to factory spec they fit perfectly. the k member and engine are same i just had engine rebuilt. when i put on the mounts the engine it was hooked to my gantry crane and the k member was on a cart. i used the crane to help get bolts lined up and put in. i also tightened them at same time. is it possible i caused the issue by tightening them without k member being perfectly level on cart and taking the full weight of engine?? is it worth loosing all the engine mount bolts and transmission mount now that it is in car and seeing if engine will settle? or am i wasting my time and i should just shim the right side. the engine had no shims before. opinions wanted. thanks
383 engine not level
- Thread starter stubbygda
- Start date
We don't know if the center link is parallel so dismiss that
Loosen the two long mount to frame bolts and Jimmy it around until it is level in the car
Tighten bolts
Loosen the two long mount to frame bolts and Jimmy it around until it is level in the car
Tighten bolts
- Local time
- 12:49 AM
- Joined
- Apr 13, 2012
- Messages
- 38,478
- Reaction score
- 139,816
- Location
- Granite Bay CA
Uhhh....
1/16" to 1/8" out of level?
This worries you? Come on, man....you haven't noticed the variances in the rest of the car? These were not hand built precision clocks or pianos. They were cars built on an assembly line. There are plus/minus tolerances all over the map on them. ONE eighth of an inch can be due to numerous things including the K member, the motor mount brackets, the rubber insulators, the car actually leaning....
Nothing to worry about.
1/16" to 1/8" out of level?
This worries you? Come on, man....you haven't noticed the variances in the rest of the car? These were not hand built precision clocks or pianos. They were cars built on an assembly line. There are plus/minus tolerances all over the map on them. ONE eighth of an inch can be due to numerous things including the K member, the motor mount brackets, the rubber insulators, the car actually leaning....
Nothing to worry about.
lol. how much off is enough to cause issues? hey these tolerances are tight compared to those on my 40 ford!
- Local time
- 12:49 AM
- Joined
- Apr 13, 2012
- Messages
- 38,478
- Reaction score
- 139,816
- Location
- Granite Bay CA
If the fan clears the shroud and the exhaust doesn't rattle, you could be off far more than you are before any problems would show up.
- Local time
- 2:49 AM
- Joined
- Oct 18, 2008
- Messages
- 3,001
- Reaction score
- 2,159
- Location
- Kindersley,Saskatchewan, Canada
440 Source mounts are not made to factory specs. Measure them they will likely be 1 inch thick. Factory are 1 1/6 to 1 1/8. Or like RemCharger said: loosen the mounts and wiggle engine from side to side till u get it level. Kim
- Local time
- 3:49 AM
- Joined
- Sep 15, 2009
- Messages
- 19,167
- Reaction score
- 37,148
- Location
- State of insanity
Yes, I'd also like to know how you eyeballed 1/16".
hey that part was easy i got my wife to do it!
i was only going by the info on their website according to them they are.
OEM Spec Engine Mount - 66-72B 66-73C 70-74E
if you look on their description they show thickness to be 1.4”. i didn’t measure mine.
thanks, i will try loosening mounts
