Fuse box......

[Jonnyuma]

Does anybody have a labeled diagram for a 76 fuse box? The fuses are numbered instead of having the particular circuit named and I'm getting kinda frustrated with it. If anyone has a chart, or even just the info and I'll make a chart and post it up here so others can print it, that would be great. Thanx, JY.



[MAGNUM GT XS22L9R]

Do you have your Operating Instructions manual that came with the car,
the one normally in the glove box?

Maybe this will help, these are for a my 1979:
01) 04 Amp - A/C heater controls, (ash receiver, radio, cluster, gear
selector and digital clock lamps
02) 20 Amp - Hazard flasher
03) Vacant
04) Vacant
05) 30 Amp - Power windows, seats & door locks
06) 20 Amp - Glove box, horns and misc. interior lights
07) 20 Amp - Tail, parking, side lights, map light, digital clock & key
buzzer
08) 20 Amp - Stop, courtesy & trunk lamps, cigar lighter
09) 05 Amp - Radio
10) 20 Amp - Back-up, turn signal lamps, A/C clutch
11) Vacant
12) Vacant
13) 05 Amp - Brake, oil & seat belt warning lamps/buzzers, tachometer,
digital clock sensor & fuel, temp & oil gauges
14) 20 Amp - Cornering lamps, speed control, power window relay, power
trunk & rear defrost
15) 30 Amp - A/C or heater blower motor
16) Vacant



[Jonnyuma]

Thanks GT, that was EXACTLY what I was looking for.

I'll have to do a little checking to see if they're the same, but it'll be a whole lot easier with that information. An owners manual would surely be helpful, but mine's looong gone and my Chiltons only gives the location of the box itself. I'm gonna use that information and make a toolbox/glovebox chart. With the exception of cornering lamps I can't imagine many differences between a '76 and a '79.



[MAGNUM GT XS22L9R]

Thanks GT, that was EXACTLY what I was looking for.

I'll have to do a little checking to see if they're the same, but it'll be a whole lot easier with that information. An owners manual would surely be helpful, but mine's looong gone and my Chiltons only gives the location of the box itself. I'm gonna use that information and make a toolbox/glovebox chart. With the exception of cornering lamps I can't imagine many differences between a '76 and a '79.

No problem, Glad I could help. I also added that info to the
"The 1978-79 Magnum XE/GT! (Info)" thread.
